Punch of percussion BOSCH GSB 19-2 RE Professional
We encourage us for cultivating the loyalty to our clients, achieving always for them the best articles to the best price. We work with first marks and endorses us have like clients to the main small and medium enterprises of our city.It consults on-line request
The fastest and versatile of his category
Powerful taladro of percussion of 2 speeds (850 W) for the fastest advance in the work
Robust design for a long useful life
Embrague Of mechanical security: antirrotación for a main security
Robust portabrocas of fast subjection
Brushes giratorias to guarantee a power of twist homogénea so much to right as to left
New handle of security with innovative subjection for a sure retention of the machine
Manguitos For radii of big movement and to avert the break of the cable
Preselection of the number of revolutions with sliding wheel to work in different materials
Soft handle Softgrip for a comfortable and sure subjection
Ø Of the collar of the husillo of 43 mm (European Norm),that can use with support for taladros
Technical data: GSB 19-2 RE Professional
Power absorbed 850 W
Number of careers in empty 0 – 1.000 / 3.000 r. p. m.
Useful power 430 W
Weight 2,6 kg
Nominal speed of rotation 0 – 770 / 1.990 r. p. m.
Pair of twist (atornillado soft) 36,0 / 15,5 Nm
Pair of nominal twist 5,2 / 2,0 Nm
Thread of connection of the husillo of taladrar 1/2" – 20 UNF
Zone of subjection 1,5 – 13 mm
Number of percussions to speed of twist in empty 0 – 17.000 / 51.000 i. p. m.
Pair of twist, máx. 36,0 / 15,5 Nm
Interval of perforación
Ø Of perforación in concrete 18 / 13 mm
Ø Of perforación in wood 40 / 25 mm
Ø Of perforación in steel 13 / 8 mm
Ø Of perforación in stone 20 / 15 mm
Ø Of perforación in mampostería 20 / 15 mm
Functions
Multiple speed
Reversible twist
Electronic control
Car Lock
Softgrip
Embrague Of security
Information on noise/vibrations
Values of measurement determined as IN 60745.
Total level of vibrations (vectorial sum of three directions)
Cut threads
Value of vibrations generated ah 2.5 m/s²
Tolerance K 1.5 m/s²
Atornillar
Value of vibrations generated ah 2.5 m/s²
Tolerance K 1.5 m/s²
Taladrar With percussion in concrete
Value of vibrations generated ah 15.0 m/s²
Tolerance K 2.0 m/s²
Taladrar In metal
Value of vibrations generated ah 3.0 m/s²
Tolerance K 1.5 m/s²
The level of noise with weighting To of the electrical tool presents the following half values:
Level of acoustic intensity 95 dB(To);
Level of acoustic power 106 dB(To).
Uncertainty K = 3 dB.
